Tank
2,000 litre to 5,000 litre main tank (separate 7 litre fresh water tank)

Pump
Low pressure pump – Comet BP125 (max. 20-bar) - large capacity (125LPM) three diaphragm pump.
Optional AR185 litre or Hypro pump.

Drive
Heavy duty PTO driveshaft comes with safety covers and quick release pins. Optional hydraulic drive.

Controls
Standard Electric - motor valves, 2 section in-cab control with electric pressure adjustment. Optional Bravo 180 automatic rate controller, 2 section (left/right) with optional. 4-section control. ISO Bus module available.

Agitation
2000L—5000L - twin brass agitators.
Optional hypro hydraulic pump.

Filtration
Full filtration system - tank filling basket, suction filter and pressure filter.

Chassis & Boom
Powder Coated, full-length chassis with adjustable drawbar and 6-stud wheel hubs. Fixed axle standard; optional adjustable height and width axle. Jockey stand supplied on all models. Optional grease lines available.
Two and three row booms available with hydraulic fold, lift, side shift on request.

Nozzles
Standard fitted with one set of TDAM air mix air inducted nozzles.

Wheels
2000L - steel rims, 11.5/80 x 15.3"
3000L—5000L- steel rims, 400/60 x 15.5" flotation tyres
