Tank
1,500 litre to 5,000 litre main tank (separate 7 litre fresh water tank)

Fan
Evolution 800mm single fan Fan capacity = 36,000 m3h / minimum 40hp required
Evolution 950mm single fan Fan capacity = 53,000 m3/h / minimum 50hp required

Pump
High pressure brass head pump – ARBHS200 (max. 50-bar) - large capacity (193LPM) four diaphragm pump featuring front external bronze manifolds and brass heads to minimise corrosion. Optional 260LPM or 300LPM high pressure pump.

Drive
Heavy duty PTO driveshaft series 8 comes with safety covers and quick release pins. Optional constant velocity (CV) shaft available.

Controls
Standard Electric - high pressure brass solenoid valves or motor valves, 2 section in-cab control with electric pressure adjustment. Optional Bravo 180 automatic rate controller, 2 section (left/right) with optional 4-section control. ISO Bus module available.

Agitation
1500L—5000L - twin brass agitators. Optional hypro hydraulic pump.

Filtration
Full filtration system - tank filling basket, single suction filter. Twin suction filters fitted to larger pump options.

Nozzles
Standard Albuz ceramic nozzles

Chassis & Boom
Powder coated, full-length chassis with adjustable drawbar and 6-stud wheel hubs. Fixed axle standard; optional adjustable height and width axle. Jockey stand supplied on all models. Hot-dipped galvanized is available on request.

Wheels
1500L—2000L - steel rims, 11.5/80 x 15.3"
3000L—5000L - steel rims, 400/60 x 15.5" flotation tyres
